NETGEAR PROSAFE M4100-12G-POE+

SPECIFICATION

General
Device Typeswitch - 12 ports - managed
Enclosure TypeRACK MOUNTABLE
Authentication MethodMAC based authentication
VLAN1 K
Network FeaturesAccess Control Lists (ACLs), concurrent VLANs, Jumbo frames support, Rapid Spanning Tree (RSTP), Multiple Spanning Tree (MSTP), Spanning Tree (STP)
Security FeaturesTra c control MAC Filter, Port Security, DHCP Snooping, IP source guard, Dynamic ARP Inspection, Spanning Tree Root Guard (STRG) , Dynamic 802.1x VLAN assignment mode, MAC Address Authentication Bypass (MAB)
QoS FeaturesAdvanced classi er-based hardware implementation for Layer 2 (MAC), Layer 3 (IP) and Layer 4 (UDP/TCP transport ports) prioritization, 8 queues for priorities, various QoS policies based on 802.1p (CoS), Di Serv can be applied to interfaces and VLANs, Automatic Voice over IP prioritization , Advanced rate limiting
Management & MonitoringWeb GUI, HTTPs CLI, Telnet, SSH SNMP, MIBs RSPAN
Routing ProtocolsL2 Switching, L2+ Static IP routing
Flash Memory32 MB
Jumbo Frame Support9Kb
MAC Address Table Size16K
StackingVirtual Chassis Stacking
Max Units In A Stack8
Performance24 Gbps, 17.8 Mpps
Power Over Ethernet (PoE)POE+
PoE Budget125W
Ports12
ProcessorBroadcom BCM53003 @ 600MHz
RAM128 MB
Status IndicatorsPower, Fan, RPS or PD Mode, Max PoE, Speed, Link, Activity

Dimensions & Weight
Depth8.19 inch
Height1.7 inch
Width13.03 inch
Weight2.596 kg

Environmental Parameters
Humidity Range Operating90% maximum relative humidity, non-condensing
Humidity Range Storage95% maximum relative humidity, non-condensing
Max Operating Temperature122°F
Max Storage Temperature158°F
Min Operating Temperature32°F
Min Storage Temperature– 4°F

Expansion / Connectivity
Manufacturer WarrantyNETGEAR ProSafe Lifetime Hardware Warranty

Miscellaneous
Safety/Compliant StandardsCE mark, commercial, FCC Part 15 Class A, VCCI Class A, Class A EN 55022 (CISPR 22) Class A, Class A C-Tick, EN 50082-1, EN 55024, CE mark, commercial, CSA certi ed (CSA 22.2 #950), UL listed (UL 1950)/cUL IEC 950/EN 60950, CB, CCC
MTBF99,094 hours

Power
FeaturesInternal power supply
Power DeviceInternal Redundant power supply
Voltage RequiredAC 120/230 V

Software / System Requirements
Software IncludedNETGEAR PROSAFE
